Derivative options available
3B37N-C0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., N: service ports 3/8" NPT, C0: Cam roller actuator, G: Soft seated spring return, 6K: M.W.P. 6000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37N-C1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., N: service ports 3/8" NPT, C1: Cam pin actuator, G: Soft seated spring return, 6K: M.W.P. 6000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37N-DL-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., N: service ports 3/8" NPT, DL: Deadmans lever, G: Soft seated spring return, 6K: M.W.P. 6000 psi Liquid 3,500 ps Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37N-H0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., N: service ports 3/8" NPT, H0: Pilot pressure range: 400 - 1,200 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37N-H1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., N: service ports 3/8" NPT, H1: Pilot pressure range: 1,400 - 4,000 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37N-H3-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., N: service ports 1/4" NPT, H3: Pilot pressure range: 44 - 115 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37N-L-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., N: service ports 3/8" NPT, L: Detented Lever, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37P-C0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., P: service ports 3/8" BSPP, C0: Cam roller actuator, G: Soft seated spring return, 6K: M.W.P. 6000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37P-C1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., P: service ports 3/8" BSPP, C1: Cam pin actuator, G: Soft seated spring return, 6K: M.W.P. 6000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37P-DL-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., P: service ports 3/8" BSPP, DL: Deadmans lever, G: Soft seated spring return, 6K: M.W.P. 6000 psi Liquid 3,500 ps Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37P-H0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., P: service ports 3/8" BSPP, H0: Pilot pressure range: 400 - 1,200 psi, Pilot connection: 1/4" BSPP female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37P-H1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., P: service ports 3/8" BSPP, H1: Pilot pressure range: 1,400 - 4,000 psi, Pilot connection: 1/4" BSPP female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37P-H3-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., P: service ports 3/8" BSPP, H3: Pilot pressure range: 44 - 115 psi, Pilot connection: 1/4" BSPP female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
3B37P-L-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
3B37: 3/8" M. St. 2/3 directional valve., P: service ports 3/8" BSPP, L: Detented Lever, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37N-C0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St. St. 2/3 cam op.valve. , N: service ports 3/8" NPT, C0: Cam roller actuator, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37N-C1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St. St. 2/3 cam op.valve. , N: service ports 3/8" NPT, C1: Cam pin actuator, G: Soft seated spring return, 6K: MWP 6,000 psi (liquid) 3,500 psi (gas), Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37N-DL-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., N: service ports 3/8" NPT, DL: Deadmans Lever, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37N-H0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., N: service ports 3/8" NPT, H0: Pilot pressure range: 400 - 1,200 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37N-H1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., N: service ports 3/8" NPT, H1: Pilot pressure range: 1,400 - 4,000 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37N-H3-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., N: service ports 3/8" NPT, H3: Pilot pressure range: 44 - 115 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37N-L-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., N: service ports 3/8" NPT, L: Detented Lever, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37P-C0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St. St. 2/3 cam op.valve. , P: service ports 3/8" BSPP, C0: Cam roller actuator, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37P-C1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St. St. 2/3 cam op.valve. , P: service ports 3/8" BSPP, C1: Cam pin actuator, G: Soft seated spring return, 6K: MWP 6,000 psi (liquid) 3,500 psi (gas), Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37P-DL-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., P: service ports 3/8" BSPP, DL: Deadmans Lever, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37P-H0-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., P: service ports 3/8" BSPP, H0: Pilot pressure range: 400 - 1,200 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37P-H1-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., P: service ports 3/8" BSPP, H1: Pilot pressure range: 1,400 - 4,000 psi, Pilot connection: 1/4" NPT female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37P-H3-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., P: service ports 3/8" BSPP, H3: Pilot pressure range: 44 - 115 psi, Pilot connection: 1/4" BSPP female., G: Soft seated spring return, 6K: M.W.P. (Valve) 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation, Suitable for use with liquid or gas.
View actuator
QTY RQD:
S-3B37P-L-G-6K DIRECTIONAL CONTROL VALVE (3B37-G)
S-3B37: 3/8" 316 St.St. 2/3 directional valve., P: service ports 3/8" BSPP, L: Detented Lever, G: Soft seated spring return, 6K: M.W.P. 6,000 psi Liquid 3,500 psi Gas, Viton seals: -10°C to +120°C, Suitable for 2/3 or 2/2 NO or NC operation., All ports are linked during changeover, Suitable for use with liquid or gas.
View actuator
QTY RQD:
